High production efficiency
High speed production: adopting advanced mechanical design and automation control system, the production speed is fast and can meet the fast delivery requirements of large-scale orders.
Continuous operation: From plastic raw material input to finished product packaging, each process is closely connected, which can achieve 24-hour uninterrupted continuous production, effectively improving equipment utilization and production capacity.
Excellent product quality
Precision control: Through precise temperature, pressure, and mold control, ensure uniform thickness and accurate size of plastic cups, high product consistency, and low defect rate.
Stable quality: The equipment operates stably, and precise control of process parameters during production ensures that each plastic cup has good strength, transparency, and appearance quality.
Main Technical Parameter
Maximum Forming Area | 850*550MM |
Maximum Forming Depth | 220MM |
Sheet Thickness Range | 0.3-3.5MM |
Maximum Sheet Roll Diameter | 1.8M |
Air Pressure Range in Use | 0.55-1.0MPa |
Main Machine Power | 22KW |
Normal Production Power Consumption | 75kw |
Normal Production Speed | 16-35 molds (for thickness below 2MM) |
Maximun Impact Load Capacity | 920kn |
Machine dimension | 12000*3000*3500 MM |
